1. Application:

Planetary Stranding Machine is mainly used for cabling conductors and insulated wires.

2. Main parameters：

2.1. Stranding cage maximum wire aperture: Φ10 mm

2.2. Max. cabling diameter: Φ40 mm

2.3. Rotation speed of cage: 52-120 rpm

2.4. Twisted pitch: 19-322 mm

2.5. Wire speed: 2.28-16.75 m/min

2.6. Capstan wheel: Φ600 mm (double wheels)

2.7. Main motor: 30 KW (AC motor)

2.8. Pay off inside cage: PND500 or PND450 (customer provides drawings)

2.9. Take up bobbin: PND560-800

Please contact me if you wonder to know more or interest it,
