Main Technical Parameter:

1. Spool outer diameter:φ630mm-φ800mm

2. Spool axle hole diameter:φ56mm-φ127mm

3. Spool max load bearing:1500kg

4. Pay-off wire diameter range:for doubling wire φ0.25mm-φ0.85mm,for single wire φ0.5mm-φ1.2mm,for insulated wire ≤φ4mm

5. Max 16 wires for each spool

6. Max pay-off speed: 250m/min

7. Pay-off tension 200 gram-6125 gram,regulated by pneumatic pressure valve

8. Spool loading method:No shaft loading,activate the top head for pneumatic lifting.Loading and unloading the spool from both side edge.

9. Drive motor:Chinese brand 2.2KW

10. Driver:Inovance frequency convertor (it can rotate both ways,forward and backward.It can keep the pendulum rod in the balance position and hold the tension unchanged when it stops

11. Security function:it can detect and alarm the broken wire while the equipment is running

12. Color:normally is RAL5015
