Small cross section automatic coiling machine


Application :

Applicable to the coiling and bundling of 0.5 ~ 6mm2 electric wire and small cross-section wire products


Technical specification:

Item

Description

Pay off mode

Self-tension pay off

Winding displacement mode

Automatic winding displacement

Number of slots of wire bundle

3 slots

Host speed

0 ~ 500 r / min

Outside diameter of wire bundle

《=Ø310mm

Pay off bobbin dimension

《=Ø630mm

Output per shift

About 700 bundles (8 hours)

Inside diameter of wire bundle

Ø120mm

Height of wire bundle

30-100mm
