No-shaft Box Type Motorized Pay Off
The machine is for unwinding wire and cable.
Model / Data Coverage
500-630mm, 630-800mm, 800-1000mm, 1000-1250 mm
- Product Details
- RFQ & FAQ
Product Overview
The machine is for unwinding wire and cable.
Wire & Cable Unwinding Pay-Off Equipment
Structural Features And Configuration
Option 01
Pneumatic brake.
Option 02
Pneumatic clamping.
Option 03
Electric lifting.
Option 04
Tension control: The tension is automatically tracked and controlled. During the pay off process, the feedback signal from the pneumatic tension frame is used to realize the constant tension of the pay off process, thereby preventing the copper wire or core wire from being stretched and deformed during the pay off process.
Option 05
Equipped with operation safety fence.
Option 06
Safety protection adopts proximity switch.
Product Images And Drawings
Frequently Asked Questions
Find answers to common questions about product selection, configuration and technical requirements.
Information required for quotation?
Intended product; material and input/output diameter; wire quantity, finished diameter, and required pitch; required speed; electrical supply and floor space.
How should the correct model be selected?
Match the required parameters, then confirm the final configuration in a product-specific technical agreement.
Are optional or customized configurations included?
Only changes and optional devices expressly listed in the final technical proposal and supply scope are included.
Which values govern the final purchase?
Catalog data are transcribed from the supplied source; the signed technical agreement governs the final scope and values.
