Belt Type Caterpillar
The machine is used for traction wire and cable.
- Product Details
- Technical Parameters
- RFQ & FAQ
Product Overview
The machine is used for traction wire and cable.
Structural Features And Configuration
The racks of the belt type traction machine are bent with thick steel plates. The structural strength is large and the appearance is beautiful.
The power system uses the frequency motor+K series spiral umbrella tooth reducer.
Adopt European-style thin -walled cylinder, it is beautiful and reliable.
Product Images And Drawings
Technical Specifications
Technical data for the 200kg, 300kg, 500kg, 800kg, 1250kg, 1600kg, 2000kg, 2500kg, 3200kg, 4000kg, 5000kg planetary stranding machine models.
| Type | 200 | 300 | 500 | 800 | 1250 | 1600 | 2000 | 2500 | 3200 | 4000 | 5000 |
|---|---|---|---|---|---|---|---|---|---|---|---|
| Cable diameter (mm) | 2-15 | 5-25 | 5-30 | 8-40 | 10-60 | 15-80 | 20-100 | 20-120 | 25-150 | 30-180 | 35-200 |
| Traction (kg) | 200 | 300 | 500 | 800 | 1250 | 1600 | 2000 | 2500 | 3200 | 4000 | 5000 |
| Speed (m/min) | 150 | 150 | 100 | 100 | 80 | 80 | 60 | 60 | 45 | 35 | 30 |
| Belt touch length (mm) | 520 | 620 | 750 | 1200 | 1500 | 1900 | 2100 | 2760 | 2900 | 3500 | 4000 |
| Belt width (mm) | 60 | 70 | 80 | 90 | 120 | 135 | 135 | 140 | 150 | 150 | 160 |
| Cylinder (pair) | 3 | 3 | 3 | 5 | 5 | 6 | 7 | 8 | 9 | 10 | 11 |
| Motor power (kw) | 3 | 4 | 5.5 | 7.5 | 11 | 15 | 15 | 15 | 18.5 | 22 | 28 |
| Motor speed (rpm) | 1500 | 1500 | 1500 | 1500 | 1500 | 1500 | 1500 | 1500 | 1500 | 1500 | 1500 |
| Center height (mm) | 1000 | 1000 | 1000 | 1000 | 1000 | 1000 | 1000 | 1000 | 1000 | 1000 | 1000 |
| Outer width (mm) | 1290 * 800 * 1450 | 1500 * 700 * 1650 | 1800 * 930 * 1650 | 2300 * 1030 * 1780 | 3000 * 1230 * 1780 | 3330 * 1230 * 1850 | 3660 * 1300 * 1850 | 3990 * 1300 * 1850 | 4320 * 1300 * 1850 | 5000 * 1300 * 1900 | 5680 * 1300 * 1900 |
