Small cross-section coiling machine ready for dispatch

Have already visited: 4304/04/2019

630mm automatic coiling machine



1.Equipment Composition:

No.

Names and specifications

Amount

Unit Price

Remarks

1

400-630mm pay off

1 Unit



2

400-630mm coiling machine

1 Unit



3

Meter-counting device

1 Unit



4

Paint: A. RAL5015   ; B. RAL7035   ; C. RAL6017   ; D. RAL5023    ;   E. or   supply by the customer

5

Operation   direction:    Left pay off          right  take   up

                                 Right pay off         left take up

6

Complete production line length. See installation schematic drawing.



2.Main technical parameters



Laying    mode:

Self-tension laying

Laying disk dimension

=∮630mm

Winding displacement mode

Automatic winding displacement

Power of motor

3HP

Number of slots  of wire bundle

3 slots

Output per shift

About 700 bundles (8 hours)

Host speed

0 ~ 500 r / min

Inside Diameter of wire   bundle

∮120mm

Outside diameter of wire bundle

=∮310mm

Height of wire bundle

30-100mm

Scope of application

Applicable to the coiling and bundling of 0.5 ~ 6mmelectric wire and small cross-section wire products




wire coiling machine.jpg
